DSPIC33EP512GP504T-E/TL
RoHS
RoHS compliant
RoHS compliantPackage 44-VFTLA Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant BUTT BOTTOM CMOS Microcontroller -40C~125C TA 60MHz 1mm 24K x 16
PDF
/
Inventory: 4665
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 44-VFTLA Exposed Pad
Surface Mount YES
Number of Pins 44
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2006
Series Automotive, AEC-Q100, dsPIC? 33EP
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Technology CMOS
Terminal Position BOTTOM
Terminal Form BUTT
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC33EP512GP504
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Memory Size 512kB
Oscillator Type Internal
Number of I/O 35
Speed 60 MIPs
RAM Size 24K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Clock Frequency 60MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 512KB 170K x 24
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 9x10b/12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
ROM (words) 174762
On Chip Program ROM Width 24
Dimensions
Height Seated (Max) 1mm
Length 6mm
Width 6mm
Compliance
RoHS Status ROHS3 Compliant
