DSPIC33EP32GS202-I/M6

Microchip Technology
RoHS
RoHS RoHS compliant
Package 28-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description 32KB flash,70MIPS,DSC optimized for digital power applications
PDF
/
Buying Options
Total Price: USD $8.54
Unit Price: USD $8.54304
≥1 USD $8.54304
≥200 USD $3.307195
≥500 USD $3.190347
≥1000 USD $3.132579
Inventory: 9367
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Mounting Type Surface Mount
Package / Case 28-UFQFN Exposed Pad
Surface Mount YES
Number of Pins 28

Technical

Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2013
Series dsPIC? 33EP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Additional Feature OPERATES UPTO 70MIPS
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Terminal Pitch 0.4mm
Base Part Number DSPIC33EP32GS202
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 21
Speed 70 MIPs
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 60MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 32KB 32K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 12x12b; D/A 2x12b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
Density 256 kb
ROM (words) 32768
On Chip Program ROM Width 8
Screening Level TS 16949

Dimensions

Height Seated (Max) 0.6mm
Length 4mm
Width 4mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
