DSPIC33EP256GP502T-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 256KB FLASH 28SSOP
PDF
/
Inventory: 2760
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 10.2mm
Height Seated (Max) 2mm
Technical
RAM (words) 16384
Format FLOATING-POINT
On Chip Program ROM Width 24
ROM (words) 87381
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 6x10b/12b
Bit Size 16
Supply Current-Max 60mA
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 256KB 85.5K x 24
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 60MHz
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 16K x 16
Speed 60 MIPs
Number of I/O 21
Oscillator Type Internal
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Pin Count 28
Base Part Number DSPIC33EP256GP502
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Digital Signal Processors
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code 3A001.A.3
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series Automotive, AEC-Q100, dsPIC? 33EP
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
