DSPIC33EP256GM706-H/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 256KB FLASH 64QFN
PDF
/
Inventory: 7628
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Technical
Number of DMA Channels 4
On Chip Data RAM Width 8
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Number of External Interrupts 5
Number of Timers 21
RAM (words) 32000
Integrated Cache NO
Format FLOATING-POINT
Screening Level TS 16949
Low Power Mode YES
Boundary Scan YES
On Chip Program ROM Width 8
Data Bus Width 16b
Data Converter A/D 30x10b/12b
Bit Size 16
Supply Current-Max 60mA
Connectivity CANbus, I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 256KB 85.5K x 24
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 60MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
RAM Size 32K x 8
Number of I/O 53
Oscillator Type Internal
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQFP-G64
Base Part Number DSPIC33EP256GM706
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Number of Terminations 64
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Automotive, AEC-Q100, dsPIC? 33EP
Published 2013
Packaging Tray
Operating Temperature -40°C~150°C TA
Physical
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 23 Weeks
