DSPIC33EP256GM706-E/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FLOATING-POINT ROHS3Compliant NO LEAD QUAD Microcontroller 3.3V -40C~125C TA 50mA 60MHz
PDF
/
Inventory: 3273
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2013
Series Automotive, AEC-Q100, dsPIC? 33EP
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 64
ECCN Code 3A001.A.3
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
RAM (words) 16384
Format FLOATING-POINT
Screening Level TS 16949
On Chip Program ROM Width 8
ROM (words) 262144
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 30x10b/12b
Bit Size 16
Supply Current-Max 50mA
Connectivity CANbus, I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 256KB 85.5K x 24
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 60MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 32K x 8
Speed 60 MIPs
Number of I/O 53
Oscillator Type Internal
Memory Size 256kB
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
JESD-30 Code S-PQCC-N64
Base Part Number DSPIC33EP256GM706
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9mm
Length 9mm
Height Seated (Max) 1mm
