DSPIC33EP128MC206T-E/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit dsPIC33E dsPIC RISC 128KB Flash 3.3V Automotive 64-Pin TQFP T/R
PDF
/
Inventory: 5351
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-TQFP
Number of Pins 64
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2013
Series Automotive, AEC-Q100, dsPIC? 33EP
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 64
ECCN Code 3A001.A.3
Terminal Finish Matte Tin (Sn)
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 70MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC33EP128MC206
Pin Count 64
Qualification Status Not Qualified
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 128kB
Oscillator Type Internal
Number of I/O 53
Speed 60 MHz
RAM Size 8K x 16
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 128KB 43K x 24
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Supply Current-Max 60mA
Bit Size 16
Data Converter A/D 16x10b/12b
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
ROM (words) 43690
On Chip Program ROM Width 24
Format FLOATING-POINT
RAM (words) 8192
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
RoHS Status ROHS3 Compliant
