DSPIC33EP128MC202-H/MM
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Digital Signal Processors & Controllers - DSP, DSC 128KB FL 16KB RAM 60MHz 28Pin
PDF
/
Inventory: 3117
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Programmable I/O 21
Max Frequency 60MHz
Core Architecture dsPIC
Number of Timers/Counters 5
Data Bus Width 16b
Watchdog Timer Yes
Data Converter A/D 6x10b/12b
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 128KB 43K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
Core Processor dsPIC
Voltage - Supply (Vcc/Vdd) 3V~3.6V
Memory Type FLASH
RAM Size 8K x 16
Speed 60 MIPs
Number of I/O 21
Oscillator Type Internal
Memory Size 128kB
Min Supply Voltage 2.95V
Max Supply Voltage 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Operating Supply Voltage 3.3V
Base Part Number DSPIC33EP128MC202
Frequency 70MHz
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Automotive, AEC-Q100, dsPIC? 33EP
Packaging Tube
Operating Temperature -40°C~150°C TA
Physical
Supplier Device Package 28-QFN-S (6x6)
Number of Pins 28
Package / Case 28-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
