DSPIC33EP128GS804-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 128KB FLASH 44TQFP
PDF
/
Buying Options
Total Price: USD $6.2
Unit Price: USD $6.1952
≥1 USD $6.1952
≥10 USD $5.676
≥100 USD $5.148
Inventory: 209
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.2mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 8
ROM (words) 131072
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 17x12b; D/A 1x12b
Bit Size 16
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 128KB 43K x 24
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 60MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 8K x 8
Speed 70 MIPs
Number of I/O 33
Oscillator Type Internal
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQFP-G44
Base Part Number DSPIC33EP128GS804
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Additional Feature ADC SAMPLE AND HOLD (5-CH 12-BIT)
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series dsPIC? 33EP
Published 2016
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 44-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 1 Weeks
