DSPIC33EP128GM306-H/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Digital Signal Processors & Controllers - DSP, DSC 128KB F 16KB R 12MCP PWM 8/8 IC/OC 2 QEI
PDF
/
Inventory: 3649
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Core Architecture dsPIC
Data Converter A/D 30x10b/12b
Connectivity I2C, IrDA, LINbus, QEI, SPI, UART/USART
Program Memory Size 128KB 43K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, Motor Control PWM, POR, PWM, WDT
Core Processor dsPIC
Memory Type FLASH
RAM Size 16K x 8
Number of I/O 53
Oscillator Type Internal
Memory Size 128kB
Base Part Number DSPIC33EP128GM306
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100, dsPIC? 33EP
Published 2013
Packaging Tube
Operating Temperature -40°C~150°C TA
Physical
Supplier Device Package 64-QFN (9x9)
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
