DSPIC33CK32MP502T-I/SS
RoHS
/
Package 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 32KB FLASH 28SSOP
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.7544
≥1 USD $2.7544
≥10 USD $2.5256
≥100 USD $2.288
Inventory: 1120
Minimum: 1
-
+
Technical Details
Dimensions
Width 5.3mm
Length 10.2mm
Height Seated (Max) 2mm
Technical
Number of DMA Channels 4
On Chip Data RAM Width 8
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Number of External Interrupts 4
Number of Timers 4
RAM (words) 8000
Integrated Cache NO
Format FLOATING-POINT
Screening Level TS 16949
Low Power Mode YES
Boundary Scan YES
On Chip Program ROM Width 8
Data Converter A/D 12x12b; D/A 3x12b
Bit Size 16
Supply Current-Max 300mA
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 32KB 32K x 8
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 64MHz
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 8K x 8
Speed 100MHz
Number of I/O 21
Oscillator Type Internal
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code R-PDSO-G28
Base Part Number DSPIC33CK32MP502
Reach Compliance Code compliant
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Number of Terminations 28
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Series dsPIC? 33CK
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
