DSPIC33CH64MP502-I/2N
RoHS
RoHS compliant
RoHS compliantPackage 28-UQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 88KB FLASH 28UQFN
PDF
/
Buying Options
Total Price: USD $3.79
Unit Price: USD $3.7928
≥1 USD $3.7928
≥10 USD $3.476
≥100 USD $3.1504
Inventory: 205
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 0.55mm
Technical
On Chip Data RAM Width 8
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Number of External Interrupts 4
RAM (words) 16000
Integrated Cache NO
Format FLOATING-POINT
Screening Level TS 16949
Low Power Mode YES
Boundary Scan YES
On Chip Program ROM Width 8
Data Converter A/D 23x12b; D/A 4x12b
Bit Size 16
Supply Current-Max 300mA
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 88KB 88K x 8
Core Size 16-Bit Dual-Core
Program Memory Type FLASH, PRAM
Clock Frequency 64MHz
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 20K x 8
Speed 180MHz, 200MHz
Number of I/O 21
Oscillator Type Internal
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQCC-N28
Base Part Number DSPIC33CH64MP502
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series dsPIC? 33CH
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-UQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 5 Weeks
