DSPIC33CH256MP505-E/M4
RoHS
RoHS compliant
RoHS compliantPackage 48-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
FIXED POINT ROHS3Compliant NO LEAD QUAD Microcontroller -40C~125C TA 64MHz 0.6mm 48K x 8
PDF
/
Buying Options
Total Price: USD $5.51
Unit Price: USD $5.5088
≥1 USD $5.5088
≥10 USD $5.06
≥100 USD $4.576
Inventory: 206
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 0.6mm
Technical
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Format FIXED POINT
Screening Level AEC-Q100; TS 16949
Low Power Mode YES
Boundary Scan YES
Data Converter A/D 31x12b; D/A 4x12b
Connectivity CANbus, I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 328kB 328k x 8
Core Size 16-Bit Dual-Core
Program Memory Type FLASH, PRAM
Clock Frequency 64MHz
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 48K x 8
Speed 180MHz, 200MHz
Number of I/O 39
Oscillator Type Internal
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQCC-N48
Terminal Pitch 0.4mm
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q100, dsPIC? 33CH
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 48-UFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
