DSPIC33CH256MP206-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 328KB FLASH 64QFN
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.016
≥1 USD $5.016
Inventory: 95
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series dsPIC? 33CH
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Terminal Pitch 0.5mm
JESD-30 Code S-PQCC-N64
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Oscillator Type Internal
Number of I/O 53
Speed 180MHz, 200MHz
RAM Size 48K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, QEI, WDT
Clock Frequency 64MHz
Program Memory Type FLASH, PRAM
Core Size 16-Bit Dual-Core
Program Memory Size 328kB 328k x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Data Converter A/D 34x12b; D/A 4x12b
Boundary Scan YES
Low Power Mode YES
Screening Level TS 16949
Format FIXED POINT
Barrel Shifter YES
Internal Bus Architecture MULTIPLE
Dimensions
Height Seated (Max) 1mm
Length 9mm
Width 9mm
Compliance
RoHS Status ROHS3 Compliant
