DSPIC30F6014T-20E/PF
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 144KB FLASH 80TQFP
PDF
/
Inventory: 1487
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Radiation Hardening No
Dimensions
Length 14mm
Height Seated (Max) 1.2mm
Technical
RAM (words) 4096
Format FIXED-POINT
Max Frequency 20MHz
On Chip Program ROM Width 24
EEPROM Size 4K x 8
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Data Converter A/D 16x12b
Bit Size 16
Connectivity CANbus, I2C, SPI, UART/USART
Program Memory Size 144KB 48K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals AC'97, Brown-out Detect/Reset, I2S, LVD, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
RAM Size 8K x 8
Speed 20 MIPS
Number of I/O 68
Oscillator Type Internal
Memory Size 144kB
Interface CAN, I2C, I2S, SPI, UART, USART
Operating Supply Voltage 5.5V
Pin Count 80
Base Part Number DSPIC30F6014
Time@Peak Reflow Temperature-Max (s) 40
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
Additional Feature ALSO OPERATES AT 3V MINIMUM SUPPLY AT 10 MHZ
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series dsPIC? 30F
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 80
Surface Mount YES
Package / Case 80-TQFP
Mounting Type Surface Mount
