DSPIC30F6014A-20E/PT
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC, DSC, 16BIT, 144KB, 40MHZ 5.5V TQFP80
PDF
/
Buying Options
Total Price: USD $13.13
Unit Price: USD $13.1296
≥1 USD $13.1296
≥10 USD $11.9328
≥100 USD $10.850488
Inventory: 564
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 12mm
Length 12mm
Height 1.05mm
Technical
Number of SPI Channels 2
Number of I2C Channels 1
Number of PWM Channels 8
Number of ADC Channels 16
Format FIXED-POINT
EEPROM Size 4K x 8
Density 1.1 Mb
Number of Timers/Counters 5
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x12b
Bit Size 16
Connectivity CANbus, I2C, SPI, UART/USART
Program Memory Size 144KB 48K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals AC'97, Brown-out Detect/Reset, I2S, LVD, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
RAM Size 8K x 8
Number of I/O 68
Oscillator Type Internal
Memory Size 144kB
Interface CAN, I2C, SPI, UART, USART
Pin Count 80
Base Part Number DSPIC30F6014A
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
Terminal Finish Matte Tin (Sn)
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series dsPIC? 30F
Published 2006
Packaging Tray
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 80
Package / Case 80-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
