DSPIC30F5013T-30I/PT
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 66KB FLASH 80TQFP
PDF
/
Buying Options
Total Price: USD $10.33
Unit Price: USD $10.325959
≥1 USD $10.325959
≥200 USD $3.996468
≥500 USD $3.855987
≥1200 USD $3.786404
Inventory: 1509
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 12mm
Height Seated (Max) 1.2mm
Technical
RAM (words) 2048
Format FIXED-POINT
On Chip Program ROM Width 24
EEPROM Size 1K x 8
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x12b
Bit Size 16
Connectivity CANbus, I2C, SPI, UART/USART
Program Memory Size 66KB 22K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals AC'97, Brown-out Detect/Reset, I2S, LVD, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
RAM Size 4K x 8
Number of I/O 68
Oscillator Type Internal
Memory Size 66kB
Interface CAN, I2C, SPI, UART, USART
Operating Supply Voltage 5.5V
Pin Count 80
Base Part Number DSPIC30F5013
Time@Peak Reflow Temperature-Max (s) 40
Frequency 30MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series dsPIC? 30F
Published 2004
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 80
Package / Case 80-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
