DSPIC30F4012-20E/ML
RoHS
/
Package 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 48KB FLASH 44QFN
PDF
/
Buying Options
Total Price: USD $21.48
Unit Price: USD $21.47855
≥1 USD $21.47855
≥10 USD $17.62345
≥100 USD $17.07245
≥500 USD $16.5224
≥1000 USD $15.9714
Inventory: 202
Minimum: 1
-
+
Technical Details
Technical
Series dsPIC? 30F
Published 2005
Packaging Tube
Operating Temperature -40°C~125°C TA
RAM (words) 1024
Format FIXED-POINT
On Chip Program ROM Width 24
EEPROM Size 1K x 8
ROM (words) 16384
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 6x10b
Bit Size 16
Connectivity CANbus, I2C, SPI, UART/USART
Program Memory Size 48KB 16K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, Motor Control PWM, QEI, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
RAM Size 2K x 8
Number of I/O 20
Oscillator Type Internal
Memory Size 48kB
Interface CAN, I2C, SPI, UART, USART
Pin Count 44
Base Part Number DSPIC30F4012
Time@Peak Reflow Temperature-Max (s) 40
Frequency 20MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Digital Signal Processors
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Physical
Number of Pins 44
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 8mm
Height Seated (Max) 1mm
