DSPIC30F3012T-30I/SO
RoHS
RoHS compliant
RoHS compliantPackage 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 24KB FLASH 18SOIC
PDF
/
Inventory: 1772
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 2.64mm
Technical
RAM (words) 2048
Format FIXED-POINT
On Chip Program ROM Width 24
EEPROM Size 1K x 8
ROM (words) 8192
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x12b
Bit Size 16
Connectivity I2C, SPI, UART/USART
Program Memory Size 24KB 8K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor dsPIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
RAM Size 2K x 8
Number of I/O 12
Oscillator Type Internal
Memory Size 24kB
Interface I2C, SPI, UART, USART
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 18
Base Part Number DSPIC30F3012
Time@Peak Reflow Temperature-Max (s) 40
Frequency 30MHz
Terminal Pitch 1.27mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Digital Signal Processors
Additional Feature ALSO OPERATES AT 2.5V MINIMUM SUPPLY AT 10MHZ
Terminal Finish Matte Tin (Sn)
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series dsPIC? 30F
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 18
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
