DSPIC30F2012T-30I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 12KB FLASH 28SOIC
PDF
/
Buying Options
Total Price: USD $8.54
Unit Price: USD $8.54304
≥1 USD $8.54304
≥200 USD $3.307195
≥500 USD $3.190347
≥1000 USD $3.132579
Inventory: 4436
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2006
Series dsPIC? 30F
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Terminal Finish Matte Tin (Sn)
Additional Feature ALSO OPERATES AT 2.5V MINIMUM SUPPLY AT 10MHZ
Subcategory Digital Signal Processors
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 250
Supply Voltage 5V
Terminal Pitch 1.27mm
Frequency 30MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DSPIC30F2012
Pin Count 28
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface I2C, SPI, UART, USART
Memory Size 12kB
Oscillator Type Internal
Number of I/O 20
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 2.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor dsPIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 12KB 4K x 24
Connectivity I2C, SPI, UART/USART
Bit Size 16
Data Converter A/D 10x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
On Chip Program ROM Width 24
Number of Programmable I/O 12
Format FIXED-POINT
RAM (words) 1024
Dimensions
Height Seated (Max) 2.64mm
Length 17.87mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
