ATXMEGA64A1U-C7U
RoHS
RoHS compliant
RoHS compliantPackage 100-VFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 64KB FLASH 100VFBGA
PDF
/
Buying Options
Total Price: USD $53.7
Unit Price: USD $53.6959
≥1 USD $53.6959
≥10 USD $44.05815
≥100 USD $42.6816
≥500 USD $41.30505
≥1000 USD $39.92755
Inventory: 105
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-VFBGA
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2013
Series AVR? XMEGA? A1U
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Subcategory Microcontrollers
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 3V
Terminal Pitch 0.65mm
Frequency 32MHz
Base Part Number ATXMEGA64
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 1.6V
Interface EBI/EMI, I2C, IrDA, SPI, UART, USART, USB
Memory Size 64kB
Oscillator Type Internal
Number of I/O 78
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 1.6V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8/16-Bit
Program Memory Size 64KB 32K x 16
Connectivity EBI/EMI, I2C, IrDA, SPI, UART/USART
Supply Current-Max 12mA
Bit Size 16
Data Converter A/D 16x12b; D/A 4x12b
Has ADC YES
DMA Channels YES
Data Bus Width 8b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 8
Address Bus Width 24
EEPROM Size 2K x 8
On Chip Program ROM Width 16
Boundary Scan YES
Low Power Mode NO
Format FIXED-POINT
Integrated Cache NO
Number of Serial I/Os 8
On Chip Data RAM Width 16
Number of DMA Channels 4
Dimensions
Height Seated (Max) 1mm
Length 7mm
Compliance
RoHS Status ROHS3 Compliant
