ATXMEGA32D4-ANR
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 8-Bit/16-Bit XMEGA AVR RISC 32KB Flash 3.3V 44-Pin TQFP T/R
PDF
/
Inventory: 3669
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 44
Additional Feature IT IS ALSO OPERATES IN 12 MHZ AT 1.6V
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 0.8mm
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number ATXMEGA32
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, IrDA, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 34
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 1.6V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Part Status Active
Pbfree Code yes
Series AVR? XMEGA? D4
Published 1999
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
EEPROM Size 1K x 8
Number of Timers/Counters 4
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 12x12b
Bit Size 16
Connectivity I2C, IrDA, SPI, UART/USART
Program Memory Size 32KB 16K x 16
Core Size 8/16-Bit
Program Memory Type FLASH
Physical
Number of Pins 44
Package / Case 44-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.2mm
