ATXMEGA192C3-MHR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 64QFN IND TEMP GREEN 1.6-3.6V
PDF
/
Inventory: 3021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2011
Series AVR? XMEGA? C3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3V
Frequency 32MHz
Base Part Number ATXMEGA192
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 1.8/3.3V
Supply Voltage-Min (Vsup) 1.6V
Interface 2-Wire, I2C, IrDA, SPI, UART, USART, USB
Memory Size 192kB
Oscillator Type Internal
Number of I/O 50
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 1.6V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8/16-Bit
Program Memory Size 192KB 96K x 16
Connectivity I2C, IrDA, SPI, UART/USART, USB
Supply Current-Max 12mA
Bit Size 16
Data Converter A/D 16x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 8b
PWM Channels YES
Number of Timers/Counters 5
ROM (words) 98304
EEPROM Size 2K x 8
Number of ADC Channels 16
Dimensions
Height Seated (Max) 1mm
Length 9mm
Compliance
RoHS Status ROHS3 Compliant
