ATTINY861A-PU
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
In a Pack of 5, Microchip, 8bit AVR Microcontroller, 20MHz, 8 kB Flash, 20-Pin PDIP
PDF
/
Buying Options
Total Price: USD $1.78
Unit Price: USD $1.7776
≥1 USD $1.7776
≥10 USD $1.628
≥100 USD $1.4696
Inventory: 1682
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 7.11mm
Length 25.98mm
Height 5.334mm
Technical
Number of SPI Channels 2
Number of I2C Channels 1
Number of PWM Channels 3
Number of ADC Channels 11
EEPROM Size 512 x 8
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 11x10b
Bit Size 8
Supply Current-Max 7mA
Connectivity USI
Program Memory Size 8KB 4K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
RAM Size 512 x 8
Number of I/O 16
Oscillator Type Internal
Memory Size 8kB
Interface SPI
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Base Part Number ATTINY861A
Frequency 20MHz
Supply Voltage 5V
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AVR? ATtiny
Published 1997
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 20
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 7 Weeks
