ATTINY816-SNR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING DUAL CMOS Microcontroller -40C~105C TA 6.9mA 20MHz 2.65mm
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.9768
≥1 USD $0.9768
≥10 USD $0.8976
≥100 USD $0.8008
Inventory: 1132
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Published 2016
Series tinyAVR? 1
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Additional Feature 2.7V MIN @ 10MHZ AND 1.8V MIN @5MHZ FREQUENCY AVAILABLE
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number ATTINY816
JESD-30 Code R-PDSO-G20
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 18
Speed 20MHz
RAM Size 512 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, WDT
Clock Frequency 20MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 8K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max 6.9mA
Bit Size 8
Data Converter A/D 12x10b; D/A 1x8b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 8192
EEPROM Size 128 x 8
On Chip Program ROM Width 8
Low Power Mode YES
RAM (words) 512
Number of Timers 4
Number of External Interrupts 18
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 2.65mm
Length 12.8mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
