ATTINY48-MU
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 4KB FLASH 32VQFN
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 65005
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.1mm
Length 5.1mm
Height 1mm
Technical
Number of I2C Channels 1
Number of PWM Channels 2
Number of ADC Channels 8
Number of Programmable I/O 24
EEPROM Size 64 x 8
ROM (words) 4096
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 8
Connectivity I2C, SPI
Program Memory Size 4KB 2K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
RAM Size 256 x 8
Number of I/O 28
Oscillator Type Internal
Memory Size 4kB
Interface 2-Wire, I2C, I2S, SPI
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number ATTINY48
Time@Peak Reflow Temperature-Max (s) 40
Frequency 12MHz
Terminal Pitch 0.5mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series AVR? ATtiny
Published 1997
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 2 Weeks
Alternative Model
