ATTINY44A-SSFR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 4KB FL 256B EE 256B SRAM 20MHz Hi +125C
PDF
/
Buying Options
Total Price: USD $0.91
Unit Price: USD $0.9064
≥1 USD $0.9064
≥10 USD $0.8184
≥100 USD $0.748
Inventory: 193
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 1997
Series AVR? ATtiny
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
Terminal Finish Matte Tin (Sn)
Additional Feature ALSO OPERATES 1.8 V MINIMUM SUPPLY AT 4 MHZ
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ATTINY44A
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Interface SPI
Memory Size 4kB
Oscillator Type Internal
Number of I/O 12
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 4KB 2K x 16
Connectivity USI
Supply Current-Max 7mA
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
ROM (words) 4096
EEPROM Size 256 x 8
Dimensions
Height Seated (Max) 1.75mm
Length 8.645mm
Compliance
RoHS Status ROHS3 Compliant
