ATTINY26L-8SI

Microchip Technology
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description 8-bit Microcontrollers - MCU AVR 2K FLSH 128B EE 128B SRAM ADC 3V
PDF
/
Inventory: 5144
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Published 1997
Packaging Tube
Operating Temperature -40°C~85°C TA
On Chip Data RAM Width 8
Number of Timers 2
RAM (words) 16
Integrated Cache NO
Low Power Mode YES
On Chip Program ROM Width 16
EEPROM Size 128 x 8
ROM (words) 1024
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 11x10b
Bit Size 8
Connectivity USI
Program Memory Size 2KB 1K x 16
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 8MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 128 x 8
Speed 8MHz
Number of I/O 16
Oscillator Type Internal
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code R-PDSO-G22
Base Part Number ATTINY26
Terminal Pitch 1.27mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Number of Terminations 20
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Series AVR? ATtiny

Physical

Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Width 7.6mm
Length 13mm
Height Seated (Max) 2.65mm
