ATTINY2313V-10MI
RoHS
/
Package 20-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 2KB FLASH 20QFN
PDF
/
Inventory: 9914
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Lead, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-WFQFN Exposed Pad
Number of Pins 20
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 1997
Series AVR? ATtiny
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish TIN LEAD
Additional Feature OPERATES AT 1.8V MINIMUM SUPPLY @ 4MHZ
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 240
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 10MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ATTINY2313
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Interface SPI, UART, USART
Memory Size 2kB
Oscillator Type Internal
Number of I/O 18
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 2KB 1K x 16
Connectivity SPI, UART/USART
Bit Size 8
Access Time 10 μs
Has ADC NO
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 2
EEPROM Size 128 x 8
Dimensions
Height Seated (Max) 0.8mm
Length 4mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
