ATTINY214-SSF
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
20MHZ 2KB SOIC14 IND 125C GREEN
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.5368
≥100 USD $0.484
Inventory: 1104
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Series tinyAVR? 1
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
Additional Feature ALSO OPERATES AT 1.8V MINIMUME SUPPLY AT 5MHZ AND 2.7V MINIMUM SUPPLY AT 10 MHZ
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 1.27mm
Reach Compliance Code compliant
JESD-30 Code R-PDSO-G14
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Oscillator Type Internal
Number of I/O 12
Speed 20MHz
RAM Size 128 x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, WDT
Clock Frequency 16MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 2KB 2K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 10x10b; D/A 1x8b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 2048
EEPROM Size 64 x 8
On Chip Program ROM Width 8
Low Power Mode YES
RAM (words) 128
RAM (bytes) 128
Number of Timers 3
Number of External Interrupts 12
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
