ATTINY20-SSU
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MICROCHIP - ATTINY20-SSU - 8 Bit MCU, AVR ATtiny Family ATtiny20 Series Microcontrollers, 12 MHz, 2 KB, 128 Byte, 14 Pins
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.6336
≥1 USD $0.6336
≥10 USD $0.572
≥100 USD $0.5192
Inventory: 3683
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.99mm
Length 8.74mm
Height 1.5mm
Technical
Number of I2C Channels 1
Number of PWM Channels 2
Number of ADC Channels 8
Data Bus Width 8b
DMA Channels NO
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 8
Supply Current-Max 5mA
Connectivity I2C, SPI
Program Memory Size 2KB 1K x 16
Core Size 8-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
RAM Size 128 x 8
Number of I/O 12
Oscillator Type Internal
Memory Size 2kB
Interface I2C, SPI
Supply Voltage-Max (Vsup) 5.5V
Operating Supply Voltage 3.3V
Base Part Number ATTINY20
Time@Peak Reflow Temperature-Max (s) 40
Frequency 12MHz
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 14
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series AVR? ATtiny
Published 1997
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
