ATTINY1614-SSNR
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 16KB FLASH 14SOIC
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.7304
≥100 USD $0.6688
Inventory: 12805
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Cut Tape (CT)
Series tinyAVR? 1
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature ALSO OPERATES AT 1.8V MINIMUME SUPPLY AT 5MHZ AND 2.7V MINIMUM SUPPLY AT 10 MHZ
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 1.27mm
Base Part Number ATTINY1614
JESD-30 Code R-PDSO-G14
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Oscillator Type Internal
Number of I/O 12
Speed 20MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 20MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 16KB 16K x 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 14x10b; D/A 3x8b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 16384
EEPROM Size 256 x 8
On Chip Program ROM Width 8
Low Power Mode YES
Integrated Cache NO
RAM (words) 2048
Number of Timers 4
Number of External Interrupts 12
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
