ATTINY1614-SSN
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
20MHZ SOIC 85C GREEN
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.7304
≥100 USD $0.6688
Inventory: 1512
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 8.65mm
Height Seated (Max) 1.75mm
Technical
On Chip Data RAM Width 8
Number of External Interrupts 12
Number of Timers 4
RAM (bytes) 2048
RAM (words) 2048
Integrated Cache NO
Low Power Mode YES
On Chip Program ROM Width 8
EEPROM Size 256 x 8
ROM (words) 16384
DAC Channels YES
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 14x10b; D/A 3x8b
Bit Size 8
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 16KB 16K x 8
Core Size 8-Bit
Program Memory Type FLASH
Clock Frequency 20MHz
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Core Processor AVR
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.8V~5.5V
RAM Size 2K x 8
Speed 20MHz
Number of I/O 12
Oscillator Type Internal
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code R-PDSO-G14
Terminal Pitch 1.27mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Additional Feature ALSO OPERATES AT 1.8V MINIMUME SUPPLY AT 5MHZ AND 2.7V MINIMUM SUPPLY AT 10 MHZ
Number of Terminations 14
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series tinyAVR? 1
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
