ATSAMV70N20B-CB
RoHS
RoHS compliant
RoHS compliantPackage 100-TFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 100TFBGA
PDF
/
Buying Options
Total Price: USD $12.43
Unit Price: USD $12.4256
≥1 USD $12.4256
≥10 USD $11.396
≥100 USD $10.322488
Inventory: 297
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9mm
Length 9mm
Height Seated (Max) 1.1mm
Technical
Number of DMA Channels 24
On Chip Data RAM Width 32
Number of Timers 12
RAM (words) 98304
Low Power Mode YES
CPU Family CORTEX-M7
On Chip Program ROM Width 32
ROM (words) 262144
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 10x12b; D/A 2x12b
Bit Size 32
Connectivity CANbus, I2C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SPI, SSC, UART/USART, USB
Program Memory Size 1MB 1M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 300MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 384K x 8
Speed 300MHz
Number of I/O 75
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.2V
Supply Voltage-Max (Vsup) 1.32V
JESD-30 Code S-PBGA-B100
Base Part Number ATSAMV70N
Terminal Pitch 0.8mm
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
HTS Code 8542.31.00.01
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100, SAM V70
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 100-TFBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
