ATSAML11D15A-YU
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING DUAL CMOS Microcontroller -40C~85C TA 32MHz 2mm 8K x 8
PDF
/
Buying Options
Total Price: USD $2.37
Unit Price: USD $2.3672
≥1 USD $2.3672
≥10 USD $2.1648
≥100 USD $1.9624
≥500 USD $1.881
Inventory: 1008
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Length 8.2mm
Height Seated (Max) 2mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 8
EEPROM Size 2K x 8
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 5x12b; D/A 1x10b
Bit Size 32
Connectivity I2C, LINbus, SPI, UART/USART
Program Memory Size 32KB 32K x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor ARM? Cortex?-M23
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.62V~3.63V
RAM Size 8K x 8
Speed 32MHz
Number of I/O 17
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.62V
Supply Voltage-Max (Vsup) 3.63V
JESD-30 Code R-PDSO-G24
Base Part Number ATSAML11D
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Series SAM L11
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 24-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
