ATSAME70Q20B-CNT
RoHS
RoHS compliant
RoHS compliantPackage 144-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 144LFBGA
PDF
/
Buying Options
Total Price: USD $29.53
Unit Price: USD $29.53265
≥1 USD $29.53265
≥10 USD $24.2326
≥100 USD $23.47545
≥500 USD $22.71735
≥1000 USD $21.9602
Inventory: 1132
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 144-LFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Cut Tape (CT)
Published 2018
Series SAM E70
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 1.2V
Terminal Pitch 0.8mm
Base Part Number ATSAME70Q
JESD-30 Code S-PBGA-B144
Supply Voltage-Max (Vsup) 1.32V
Supply Voltage-Min (Vsup) 1.08V
Oscillator Type Internal
Number of I/O 114
Speed 300MHz
RAM Size 384K x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M7
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency 20MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 1MB 1M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, SPI, UART/USART, USB
Bit Size 32
Data Converter A/D 24x12b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
Address Bus Width 24
On Chip Program ROM Width 8
Screening Level TS 16949
External Data Bus Width 16
Dimensions
Height Seated (Max) 1.4mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
