ATSAME70Q20B-CFN
RoHS
RoHS compliant
RoHS compliantPackage 144-UFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 144UFBGA
PDF
/
Inventory: 6404
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 0.6mm
Technical
External Data Bus Width 16
Screening Level TS 16949
On Chip Program ROM Width 8
Address Bus Width 24
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 24x12b; D/A 2x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, SPI, UART/USART, USB
Program Memory Size 1MB 1M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 20MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
RAM Size 384K x 8
Speed 300MHz
Number of I/O 114
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.08V
Supply Voltage-Max (Vsup) 1.32V
JESD-30 Code S-PBGA-B144
Base Part Number ATSAME70Q
Terminal Pitch 0.4mm
Supply Voltage 1.2V
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Number of Terminations 144
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series SAM E70
Published 2018
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 144-UFBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
