ATSAME70N20A-AN
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 100LQFP
PDF
/
Buying Options
Total Price: USD $74.87
Unit Price: USD $74.8657
≥1 USD $74.8657
≥10 USD $72.5268
≥100 USD $70.18695
≥500 USD $67.8471
≥1000 USD $60.8285
Inventory: 1253
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 100-LQFP
Number of Pins 100
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Published 2016
Series SAM E70
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 1.2V
Terminal Pitch 0.5mm
Frequency 300MHz
Base Part Number ATSAME70N
Supply Voltage-Max (Vsup) 1.32V
Supply Voltage-Min (Vsup) 1.08V
Interface CAN, Ethernet, I2C, IrDA, LIN, MMC, SD, SDIO, SPI, UART, USART, USB
Memory Size 1MB
Oscillator Type Internal
Number of I/O 75
RAM Size 384K x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M7
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 1MB 1M x 8
Connectivity CANbus, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, SPI, UART/USART, USB
Bit Size 32
Data Converter A/D 10x12b; D/A 2x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 14
ROM (words) 1048576
Core Architecture ARM
On Chip Program ROM Width 8
CPU Family CORTEX-M7
Boundary Scan YES
Low Power Mode YES
Integrated Cache YES
On Chip Data RAM Width 8
Time-Min SECONDS
Number of DMA Channels 24
Dimensions
Height Seated (Max) 1.6mm
Compliance
RoHS Status ROHS3 Compliant
