ATSAME70J19B-ANT
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
CM7,512KB FLASH,256KB SRAM,LQFP6
PDF
/
Buying Options
Total Price: USD $10.32
Unit Price: USD $10.3224
≥1 USD $10.3224
≥10 USD $9.372
≥100 USD $8.5096
Inventory: 531
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.6mm
Technical
External Data Bus Width 16
Screening Level TS 16949
On Chip Program ROM Width 8
Address Bus Width 24
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 5x12b; D/A 1x12b
Bit Size 32
Connectivity CANbus, Ethernet, I2C, IrDA, LINbus, SPI, UART/USART, USB
Program Memory Size 512KB 512K x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 16MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M7
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.7V~3.6V
RAM Size 256K x 8
Speed 300MHz
Number of I/O 44
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQFP-G64
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series SAM E70
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 64-LQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
