ATSAME51N20A-AU-EFP
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT FLASH
PDF
/
Buying Options
Total Price: USD $13.38
Unit Price: USD $13.38226
≥1 USD $13.38226
≥10 USD $12.62477
≥100 USD $11.91016
≥500 USD $11.236
≥1000 USD $10.6
≥3000 USD $10
Inventory: 3242
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.2mm
Technical
Screening Level ISO/TS-16949
On Chip Program ROM Width 8
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 28x12b; D/A 2x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, I2C, IrDA, LINbus, MMC/SD, QSPI, SPI, UART/USART, USB
Program Memory Size 1MB 1M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 48MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M4F
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.71V~3.63V
RAM Size 256K x 8
Speed 120MHz
Number of I/O 81
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.71V
Supply Voltage-Max (Vsup) 3.63V
JESD-30 Code S-PQFP-G100
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series SAM E53
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 100-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
