ATSAMD21J17D-MF
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 128KB FLASH 64QFN
PDF
/
Buying Options
Total Price: USD $3.26
Unit Price: USD $3.256
≥1 USD $3.256
≥10 USD $2.9392
≥100 USD $2.6576
Inventory: 340
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount, Wettable Flank
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TA
Packaging Tray
Series Automotive, AEC-Q100, SAM D21J
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Matte Tin (Sn)
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Reach Compliance Code compliant
Time@Peak Reflow Temperature-Max (s) 30
JESD-30 Code S-XQCC-N64
Supply Voltage-Max (Vsup) 3.63V
Supply Voltage-Min (Vsup) 1.62V
Oscillator Type Internal
Number of I/O 52
Speed 48MHz
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.63V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M0+
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 128KB 128K x 8
Connectivity I2C, LINbus, SPI, UART/USART, USB
Bit Size 32
Data Converter A/D 20x12b; D/A 1x10b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
On Chip Program ROM Width 8
Screening Level TS 16949
Dimensions
Height Seated (Max) 1mm
Length 9mm
Width 9mm
Compliance
RoHS Status RoHS Compliant
