ATSAMD21J17D-CUT
RoHS
RoHS compliant
RoHS compliantPackage 64-UFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
64BGA 85C GREEN1.6-3.6V48MHZ
PDF
/
Inventory: 9019
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Data Converter A/D 20x12b; D/A 1x10b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
On Chip Program ROM Width 8
Screening Level TS 16949
Bit Size 32
Connectivity I2C, LINbus, SPI, UART/USART, USB
Program Memory Size 128KB 128K x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M0+
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.62V~3.63V
RAM Size 16K x 8
Speed 48MHz
Number of I/O 52
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.62V
Supply Voltage-Max (Vsup) 3.63V
JESD-30 Code S-PBGA-B64
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code compliant
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series SAM D21J
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 0.65mm
Length 5mm
Width 5mm
Compliance
RoHS Status RoHS Compliant
Physical
Surface Mount YES
Package / Case 64-UFBGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
