ATSAMD21G17A-AFT
RoHS
RoHS compliant
RoHS compliantPackage 48-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ARM? Cortex?-M0+ SAM D21G Microcontroller IC 32-Bit 48MHz 128KB (128K x 8) FLASH 48-TQFP (7x7)
PDF
/
Inventory: 6610
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-TQFP
Number of Pins 48
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2015
Series Automotive, AEC-Q100, SAM D21G
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 48MHz
Base Part Number ATSAMD21G17
Operating Supply Voltage 3.3V
Interface I2C, I2S, LIN, SPI, UART, USART, USB
Memory Size 128kB
Oscillator Type Internal
Number of I/O 38
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M0+
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 128KB 128K x 8
Connectivity I2C, LINbus, SPI, UART/USART, USB
Bit Size 32
Data Converter A/D 14x12b; D/A 1x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 6
Core Architecture ARM
Dimensions
Height Seated (Max) 1.2mm
Length 7mm
Compliance
RoHS Status ROHS3 Compliant
