ATSAMD20J15A-AN
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING QUAD CMOS Microcontroller -40C~105C TA 48MHz 1.2mm 4K x 8
PDF
/
Inventory: 2474
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Contact Plating Tin
Mounting Type Surface Mount
Package / Case 64-TQFP Exposed Pad
Surface Mount YES
Number of Pins 64
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Published 2015
Series SAM D20J
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 48MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number ATSAMD20J15
Supply Voltage-Max (Vsup) 3.63V
Supply Voltage-Min (Vsup) 1.62V
Interface I2C, SPI, UART, USART
Memory Size 32kB
Oscillator Type Internal
Number of I/O 52
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M0+
Peripherals Brown-out Detect/Reset, POR, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 32KB 32K x 8
Connectivity I2C, SPI, UART/USART
Bit Size 32
Data Converter A/D 20x12b; D/A 1x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 32b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 8
Density 256 kb
Core Architecture ARM
Number of Programmable I/O 52
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
RoHS Status ROHS3 Compliant
