ATSAMC21J17A-ANT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
64TQFP, 105C Temp, Green, 5V, 48MHZ, T&r 64 TQFP 10X10X1MM T/r
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 1.2mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 8
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 20x12b, 3x16b; D/A 1x10b
Bit Size 32
Connectivity CANbus, I2C, LINbus, SPI, UART/USART
Program Memory Size 128KB 128K x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 48MHz
Peripherals Brown-out Detect/Reset, DMA, POR, WDT
Core Processor ARM? Cortex?-M0+
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 16K x 8
Speed 48MHz
Number of I/O 52
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PQFP-G64
Base Part Number ATSAMC21
Terminal Pitch 0.5mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SAM C21
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 64-TQFP Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 25 Weeks
