ATSAMC21E15A-AUT
RoHS
RoHS compliant
RoHS compliantPackage 32-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 32KB FLASH 32TQFP
PDF
/
Buying Options
Total Price: USD $5.53
Unit Price: USD $5.52995
≥1 USD $5.52995
≥10 USD $4.53815
≥100 USD $4.39565
≥500 USD $4.2541
≥1000 USD $4.11255
Inventory: 1874
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 27 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7mm
Length 7mm
Height Seated (Max) 1.2mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 8
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 10x12b, 1x16b; D/A 1x10b
Bit Size 32
Connectivity CANbus, I2C, LINbus, SPI, UART/USART
Program Memory Size 32KB 32K x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 48MHz
Peripherals Brown-out Detect/Reset, DMA, POR, WDT
Core Processor ARM? Cortex?-M0+
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
RAM Size 4K x 8
Speed 48MHz
Number of I/O 26
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PQFP-G32
Base Part Number ATSAMC21
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.8mm
Supply Voltage 5V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 32
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SAM C21
Published 2016
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 32-TQFP
Mounting Type Surface Mount
