ATSAM4LS8BA-AU
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-bit SAM4L ARM Cortex M4 RISC 512KB Flash 1.8V/ 2V/ 2.3V/ 3.3V 64-Pin LQFP Tray
PDF
/
Buying Options
Total Price: USD $9.65
Unit Price: USD $9.6536
≥1 USD $9.6536
≥10 USD $8.8
≥100 USD $7.9552
Inventory: 234
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Technical
Number of ADC Channels 7
CPU Family CORTEX-M4
Core Architecture ARM
ROM (words) 524288
Number of Timers/Counters 3
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 7x12b; D/A 1x10b
Bit Size 32
Supply Current-Max 18.24mA
Connectivity I2C, IrDA, LINbus, SPI, UART/USART, USB
Program Memory Size 512KB 512K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M4
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.68V~3.6V
RAM Size 64K x 8
Number of I/O 48
Oscillator Type Internal
Memory Size 512kB
Interface I2C, IrDA, LIN, SPI, UART, USART, USB
Operating Supply Voltage 1.8V
Qualification Status Not Qualified
Base Part Number ATSAM4LS8
Time@Peak Reflow Temperature-Max (s) 30
Frequency 48MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SAM4L
Published 2013
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Weight 342.689036mg
Number of Pins 64
Package / Case 64-TQFP Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 24 Weeks
