ATSAM3X4CA-AU
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-bit SAM3X ARM Cortex M3 RISC 256KB Flash 1.8V/2.5V/3.3V 100-Pin LQFP
PDF
/
Buying Options
Total Price: USD $9.68
Unit Price: USD $9.68
≥1 USD $9.68
≥10 USD $8.8088
≥100 USD $7.964
Inventory: 1016
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mounting Type Surface Mount
Package / Case 100-LQFP
Surface Mount YES
Number of Pins 100
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2012
Series SAM3X
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Frequency 84MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ATSAM3X
Operating Supply Voltage 3.6V
Interface CAN, Ethernet, I2C, IrDA, LIN, MMC, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 63
RAM Size 64K x 8
Memory Type FLASH, ROM
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity CANbus, Ethernet, I2C, IrDA, LINbus, Memory Card, SPI, SSC, UART/USART, USB
Bit Size 32
Data Converter A/D 16x12b; D/A 2x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
Number of Timers/Counters 1
Core Architecture ARM
CPU Family CORTEX-M3
Number of ADC Channels 16
Number of PWM Channels 4
Number of DAC Channels 2
Dimensions
Height 1.45mm
Length 14mm
Width 14mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
