ATSAM3S1CA-AU
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Lead Free ROHS3Compliant Surface Mount FLASH Microcontroller 85C 64MHz 1.45mm 16K x 8
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7051
≥1 USD $6.7051
≥10 USD $5.5024
≥100 USD $5.33045
≥500 USD $5.1585
≥1000 USD $4.98655
Inventory: 10109
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 14mm
Length 14mm
Height 1.45mm
Technical
Number of SPI Channels 1
Number of I2C Channels 2
Number of PWM Channels 4
Number of ADC Channels 16
Number of UART Channels 2
Number of Programmable I/O 79
Max Frequency 64MHz
Core Architecture ARM
Address Bus Width 32b
Number of Timers/Counters 6
Data Bus Width 32b
Watchdog Timer Yes
Data Converter A/D 15x10/12b; D/A 2x12b
Connectivity EBI/EMI, I2C, Memory Card, SPI, SSC, UART/USART, USB
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor ARM? Cortex?-M3
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
Memory Type FLASH
RAM Size 16K x 8
Speed 64MHz
Number of I/O 79
Oscillator Type Internal
Memory Size 64kB
Min Supply Voltage 1.62V
Max Supply Voltage 3.6V
Interface 2-Wire, EBI/EMI, I2C, I2S, MMC, SPI, UART, USART, USB
Operating Supply Voltage 3.3V
Base Part Number ATSAM3S1
Frequency 64MHz
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series SAM3S
Published 1997
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Supplier Device Package 100-LQFP (14x14)
Number of Pins 100
Package / Case 100-LQFP
Mounting Type Surface Mount
Mount Surface Mount
