ATSAM3N1AB-MU
RoHS
RoHS compliant
RoHS compliantPackage 48-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ARM MCU, SAM32 Family SAM 3N Series Microcontrollers, ARM Cortex-M3, 32bit, 48 MHz, 64 KB, 8 KB
PDF
/
Buying Options
Total Price: USD $3.05
Unit Price: USD $3.0536
≥1 USD $3.0536
Inventory: 795
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 7mm
Height Seated (Max) 0.9mm
Technical
Number of Programmable I/O 32
CPU Family CORTEX-M3
Core Architecture ARM
Number of Timers/Counters 6
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 8x10b
Bit Size 32
Connectivity I2C, IrDA, SPI, UART/USART
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor ARM? Cortex?-M3
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
RAM Size 8K x 8
Number of I/O 34
Oscillator Type Internal
Memory Size 64kB
Interface I2C, IrDA, SPI, UART, USART
Power Supplies 1.83.3V
Supply Voltage-Max (Vsup) 1.95V
Qualification Status Not Qualified
Base Part Number ATSAM3N
Frequency 48MHz
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series SAM3N
Published 1997
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 48
Package / Case 48-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
