ATMEGA88-20MUR
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 8KB FLASH 32VQFN
PDF
/
Buying Options
Total Price: USD $5.91
Unit Price: USD $5.9071
≥1 USD $5.9071
≥10 USD $4.8469
≥100 USD $4.6949
≥500 USD $4.54385
≥1000 USD $4.3928
Inventory: 4114
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 32-VFQFN Exposed Pad
Number of Pins 32
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 1997
Series AVR? ATmega
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 32
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 3V
Terminal Pitch 0.5mm
Frequency 20MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number ATMEGA88
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 2.7V
Interface I2C, SPI, UART, USART
Memory Size 8kB
Oscillator Type Internal
Number of I/O 23
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 2.7V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor AVR
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 8KB 4K x 16
Connectivity I2C, SPI, UART/USART
Supply Current-Max 12mA
Bit Size 8
Data Converter A/D 8x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
ROM (words) 4096
EEPROM Size 512 x 8
On Chip Program ROM Width 16
Boundary Scan NO
Low Power Mode YES
Format FIXED-POINT
Integrated Cache NO
RAM (words) 1024
Number of Serial I/Os 1
Number of External Interrupts 2
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 1mm
Length 5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
